Mean Well 12VDC PFC Power Supply IP64 Class 2 – PLN-60-12
$25.30
3 in stock
| SPECIFICATIONS: | |
|---|---|
| Input Voltage | 90~295Vac |
| C.V. Output Voltage | 12.0 Volts |
| C.V. Max Current | 5.000 Amps |
| Max Output Power | 60 Watts |
| Constant Current | 5.000 Amps |
| C.C. Voltage Min | 8.40 Vdc |
| C.C. Voltage Max | 12.00 Vdc |
- MEAN WELL PLN-60-12 constant current or constant voltage LED power supply
- AC input: 90~295Vac
- Operating temperature: -30~+50°C
- Class 2 power unit, Pass LPS
- Built-in constant current limiting circuit with adjustable OCP level
- Built-in active PFC > 0.9 at operation of 75% of rated load or higher
- High efficiency
- Fully isolated plastic case with IP64 rating
- Protections: short circuit / over current / over voltage / over temperature
- Operates: CV or CC Mode
SKU: PLN-60-12
| Weight | 0.453 kg |
|---|---|
| Dimensions | 28 × 8 × 10 cm |
